OASYS Elite

OASYS 70 Series Spring Arm
70 Series

OASYS Elite spring arms are the newest addition to the product family. This spring arm is the highest quality spring arm in the market today and its longevity is unparalleled.

This unique product offers all the features of the OASYS 2001/3001 and much more. The OASYS Elite series is capable of supporting loads up to 30kg (66lb) and can carry devices such as surgical lights, surgical displays, cameras and other peripheral devices.

  • The 2075 series is offered in load ranges of 3-13kg (7-29lbs) and 10-20kg (22-44lbs)
  • 3075 series is offered in load ranges of 10-20kg (22-44lbs) and 20-30kg (44-66lbs).
  • The LCH75 series is offered in load ranges of 60-250Nm
70 Series
OASYS 70 Series medical spring arm

COMMITTED TO QUALITY.
COMMITTED TO YOU.

  • Ceiling mount single
  • Ceiling mount dual
  • Wall Mount
  • Floor Stands/Mobile Stands
  • Accommodates loads up to 20kg (44lbs)
  • Precise vertical calibration keeps brackets consistently horizontal
  • Excellent cable management abilities with clips to hold cables securely
  • Available in 3p, 5p, 7p, 9p full rotation
  • Option 330° rotation stop that has been rigorously tested to avoid breakage that can be added in the field or at the time of purchase
  • Available for wall mount, ceiling mount, floor stand mount and Central Axis
  • Easy to mount and dismount.
  • Multiple colors RAL colors of the arm
  • New Optional colors for the end covers
  • New Height limit adjustment through the window cover makes for hassle free field adjustment without removal of the covers
  • New dual option load adjustment through the window cover, as well as through the stem cover makes for easy field adjustment without removal of the covers
  • New expanded load range of 10kg (22lbs) with each arm minimizes the number of part numbers or SKU’s that need to be inventoried
  • New vertical range of +45 degrees, minus 75 degrees makes the 2075 arm the most versatile in the market for all types of procedures.
  • Accommodates loads up to 30kg (66lbs)
  • Precise vertical calibration keeps brackets consistently horizontal
  • Excellent cable management abilities with clips to hold cables securely
  • Option 330° rotation stop that has been rigorously tested to avoid breakage that can be added in the field or at the time of purchase
  • Available in 360° rotation with slip rings
  • Available for wall mount, ceiling mount, floor stand mount and Central Axis
  • Easy to mount and dismount
  • Multiple colors RAL colors of the arm
  • New optional colors for the end covers
  • Needle bearings for smooth rotation of the connected device
  • 3075 device end fits works with most Monitor yokes including OASYS Monitor yokes
  • 40mm fixed end stem fits industry standard extension arm sleeves
  • Heavy duty fixed end pin stop that has been rigorously tested to avoid breakage
  • Brake screw on the device end with flat head or allen key tool adjustment
  • Option for 32mm fixed end stem fits industry standard extension arm sleeves for normal light heads making it simple to use most existing central axis in the field
  • New Height limit adjustment through the window cover makes for hassle free field adjustment without removal of the covers
  • New dual option load adjustment through the window cover, as well as through the stem cover makes for easy field adjustment without removal of the covers
  • New expanded load range of 10kg (22lbs) with each arm minimizes the number of part numbers or SKU’s that need to be inventoried
  • New vertical range of +45 degrees, -75 degrees makes the 3075 arm the most versatile in the market for all types of procedures.
  • Accommodates torques from 60 to 250Nm
  • Perfect choice for low ceiling applications
  • Dual brake screw design for increased longevity
  • Available in 360° rotation 3p, 5p, 7p or 9p
  • Available for wall mount, ceiling mount, floor stand mount and Central Axis
  • Easy to mount and dismount
  • Multiple colors RAL colors of the arm
  • New optional colors for the end covers
  • Needle bearings for smooth rotation of the connected device
  • 32mm fixed end stem fits industry standard extension arm sleeves for normal light heads making it simple to use most existing central axis in the field
  • New Height limit adjustment makes for hassle free field adjustment
  • New dual option load adjustment under the cover, as well as through the stem cover makes for easy field adjustment
  • New expanded torque range with each arm minimizes the number of part numbers or SKU’s that need to be inventoried
  • New vertical range of +45 degrees, minus 75 degrees makes the 2070 arm the most versatile in the market for all types of procedures.
  • The LCH75 is available with a measured torque range of 105-200Nm.
  • Approvals: UR, URC, CE
